BT RANGE

Product Features

Torque Range:

• 30 to 500 Nm (direct)

• Up to 8,000 Nm upon request

• 10 to 180 rpm (direct)

Types of Controls:

• Electromechanical: SWITCH

• Integrated LOGIC – New Version (v2)

• Integrated INTELLI+ ® – New Version (v3)

BC Function and Regulation Classification:

• On-Off: Class A+

• Positioning: Class B

• Modulation: Class III+

Environment:

• IP68 / C4 up to C5-M / T: -60°C to +70°C

• Low-temperature option down to -60°C / High-temperature option up to +90°C (high-temperature option for SWITCH version)

Product Advantages

INNOVATIVE, RELIABLE, AND MODULAR DESIGN

Completely new, unique design for multi-turn applications based on market demands and BC’s experience and methodology.

Product architecture, torque, and speed ranges tailored to customer requirements.

Highly robust design: IP68, double sealing system, powder coating (up to C5-M), low- and high-temperature versions (options from -60°C to +90°C).

Innovative features: new adjustable torque sensor cam block, new internal modular design for a compact form factor, and position sensor supporting up to 5000 revolutions.

HIGHER PERFORMANCE TO MEET THE MOST DEMANDING CONDITIONS

• 30 to 500 Nm (direct) and beyond with a gearbox.

• Wide speed range, up to 180 rpm.

• Wide stem passage with sealed tube, easy to install.

• Irreversibility at any speed without additional components.*

• High-resolution Class III+ regulation (performance and resilience exceed EN15714-2 requirements).

EASY INSTALLATION AND MAINTENANCE

• Simple commissioning: non-intrusive settings for LOGIC and INTELLI+ ® versions, quick connector, configurable relays for electronic versions.

• Large LCD screen on the LOGIC version for easy commissioning and local control management; easily adjustable in four directions with simple selection.

• Manual control without declutching for quick on-site intervention with a dual-speed option.

• Mechanical position indicator on SWITCH versions for quick valve position check at a glance.

• Fieldbus option available, including all standard market protocols: Profibus (DPV1, Simple or Redundant), Modbus, and more.

INTELLI+ ®: An Advanced Control Solution

• Simple and intuitive control with an LCD screen providing clear status of the actuator and control system.

• Advanced monitoring and diagnostic functions in the INTELLI+ ® integrated control: emergency shutoff system, partial stroke test, timer, customizable alarms, programmable signal relays, operation tracking, and more.

Excludes BT25 and BT50 at 120 rpm and 180 rpm.
